| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_008T02_9000003796_26328cztM0_level2.evt | modeM0/AS1A09_008T02_9000003796_26328cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,372,160 | 102,539,520 |
| Size | 497.2 MB | 97.8 MB |
| Events in quadrant A | 3,236,616 | 681,733 |
| Events in quadrant B | 3,274,729 | 700,441 |
| Events in quadrant C | 4,083,200 | 650,355 |
| Events in quadrant D | 4,775,986 | 641,219 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13599 | 0 |
| B | 0 | 13648 | 0 |
| C | 0 | 16239 | 0 |
| D | 0 | 18404 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6185 | 24 | 0.388036% |
| B | 6185 | 39 | 0.630558% |
| C | 6185 | 236 | 3.815683% |
| D | 6185 | 339 | 5.481002% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7485 | 6186 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7485 | 6186 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7485 | 6186 | 67 | 67 | 0.90% | 1.08% |  |
| D | 7485 | 6186 | 267 | 267 | 3.57% | 4.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 20608 | 121.42 | 830 | 815 | 163.0 |
| A | 13 | 254 | 10820 | 61.37 | 830 | 815 | 163.0 |
| A | 0 | 226 | 7180 | 39.05 | 830 | 815 | 163.0 |
| B | 0 | 230 | 28304 | 178.85 | 832 | 814 | 153.7 |
| B | 12 | 111 | 17659 | 109.6 | 832 | 814 | 153.7 |
| B | 11 | 111 | 15996 | 98.78 | 832 | 814 | 153.7 |
| C | 3 | 233 | 852600 | 4769.71 | 788 | 793 | 178.6 |
| C | 14 | 238 | 129633 | 721.44 | 788 | 793 | 178.6 |
| C | 2 | 16 | 24003 | 129.96 | 788 | 793 | 178.6 |
| D | 1 | 52 | 1679557 | 9145.99 | 782 | 763 | 183.6 |
| D | 11 | 176 | 94375 | 509.99 | 782 | 763 | 183.6 |
| D | 2 | 234 | 26821 | 141.96 | 782 | 763 | 183.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
